OEM manufacturer Sany Final Drive - Final Drive Motor WTM-09 – WEITAI Detail:
Model |
Max Output Torque (Nm) |
Max Working Pressure (Mpa) |
Max Output Speed (r/min) |
Applicable Tonnage(T) |
WTM-09 |
11500 |
31.5 |
50 |
7-9T |
•WTM-09 Final Drive is used for 7~9 Ton Hydraulic Excavator traveling.
•WTM-09 Travel Motor is interchangeable with PHV-5B, DM09, MAG-50VP, GM10VA, JMV047 Travel Motors.
Supply Ability | 2000 Pieces/ Month |
Applicable Industries | Case Excavators |
Brand Name | Weitai |
Warranty | 1 Year |
◎ Lead Time
Quantity(Pieces) | 1 – 10 | 11 – 100 | >100 |
Est. Time(days) | 2 | 20 | Negotiable |
◎ Features
•WTM-09 series Final Drive integrate high efficiency Travel Motor with Gearbox reducer.
•WTM-09 Travel Motor uses a dual displacement Swash Plate Piston Motor.
•WTM-09 Final Drive is with Freewheel function.
•WTM-09 Final Drive is with compact structure and small volume.
•The Gearbox reducer is with high torque and high durability.
•Our Travel Motor is widely used in Hydraulic Excavators and other track driving machines.
◎ Specifications
Motor Displacement |
34/53 cc/r |
Working pressure |
30 Mpa |
Speed control pressure |
2~7 Mpa |
Ratio options |
45.57 |
Max. torque of Gearbox |
10500 N.m |
Max. speed of Gearbox |
51 rpm |
Machine application |
7~9 Ton |
◎ Connection
Frame connection diameter |
210mm |
Frame flange bolt |
12-M16 |
Frame flange P.C.D. |
250mm |
Sprocket connection diameter |
265mm |
Sprocket flange bolt |
12-M104 |
Sprocket flange P.C.D. |
300mm |
Flange distance |
80mm |
Approximate weigth |
95kg (210lbs) |
Most of our WTM Travel Motor standard models are with stock and send out immediately.
Freewheel is optional for special requirements.
Komatsu Final Drive application machiens:
PC07, PC12R-8, PC14R2, PC15R8, PC18mr-2, PC20-6, PC20, PC20MR-2, PC20R8, PC27MR-1, PC27R8, PC28UU-2E, PC30, PC30-6, PC35, PC40, PC45, PC45-1, PC50, PC56, PC60,PC78, PC80, PC80mr-3, PC88, PC100, PC110-7, PC120, PC128UU, PC130, PC135, PC150.
Product detail pictures:
