High Quality Travel Motor Gearbox - Final Drive Motor WTM-40 – WEITAI Detail:

WTM-40 Final Drive is consisted of Swash-plate Piston Motor integrated with high strength planetary gearbox. It is widely used for Excavators, Drilling Rigs, Mining Equipment and other Crawler Equipment.



Model

Max Output Torque (Nm)

Max Working Pressure (Mpa)

Max Output Speed (r/min)

Applicable Tonnage(T)

WTM-40

46000

34.5

50

25-30T

◎ Features

Swash-plate Axial Piston Motor with high efficiency.
Double speed Motor with large ration for widely usage.
Build-in parking brake for safety.
Extremely compact volume and light weight.
Reliable quality and high durability.
Travel smoothly with very low noisy.
Optional Free-wheel device.
Automatic speed changing function is optional.

2

◎ Specifications

Motor Displacement

95/180 cc/r

Working pressure

31.5 Mpa

Speed control pressure

2~7 Mpa

Ratio options

48

Max. torque of Gearbox

43200 N.m

Max. speed of Gearbox

50 rpm

Machine application

25~30 Ton

◎ Connection

Frame connection diameter

300mm

Frame flange bolt

30-M16

Frame flange P.C.D.

340mm

Sprocket connection diameter

402mm

Sprocket flange bolt

30-M16

Sprocket flange P.C.D.

440mm

Flange distance

98mm

Approximate weigth

380kg (840lbs)

travel-motor

WAll our products are warranted for ONE FULL YEAR from the date of delivery against defects in materials and workmanship.
This warranty does not cover parts that are worn out through the course of normal operation or are damaged through negligence.
We serious remind that unclean hydraulic oil will definitely cause damage to your Hydraulic components. And this damage is not included in the warranty range. So we strongly suggest you to use new clean oil or make sure the system oil are clean when using our parts.


Product detail pictures:
