High Quality for Eaton Travel Motor - Final Drive Motor WTM-60 – WEITAI Detail:

WTM-60 Final Drive is consisted of Swash-plate Piston Motor integrated with high strength planetary gearbox. It is widely used for Excavators, Drilling Rigs, Mining Equipment and other Crawler Equipment.
It is interchangeable with TM50VC, MAG-230VP-6000, GM60VA, JMV-155 Travel Motors.

Model

Max Output Torque (Nm)

Max Working Pressure (Mpa)

Max Output Speed (r/min)

Applicable Tonnage(T)

WTM-60

60000

34.5

50

30-36T

◎ Features

Swash-plate Axial Piston Motor with high efficiency.
Double speed Motor with large ration for widely usage.
Build-in parking brake for safety.
Extremely compact volume and light weight.
Reliable quality and high durability.
Travel smoothly with very low noisy.
Optional Free-wheel device.
Automatic speed changing function is optional.

2

◎ Specifications

Motor Displacement

110/180 cc/r

Working pressure

35 Mpa

Speed control pressure

2~7 Mpa

Ratio options

64.8

Max. torque of Gearbox

63680 N.m

Max. speed of Gearbox

42 rpm

Machine application

30~36 Ton

◎ Connection

Frame connection diameter

380mm

Frame flange bolt

26-M120

Frame flange P.C.D.

440mm

Sprocket connection diameter

450mm

Sprocket flange bolt

18-M24

Sprocket flange P.C.D.

492mm

Flange distance

102.5mm

Approximate weigth

500kg (1100lbs)



3

All our products are warranted for ONE FULL YEAR from the date of delivery against defects in materials and workmanship.
This warranty does not cover parts that are worn out through the course of normal operation or are damaged through negligence.
We serious remind that unclean hydraulic oil will definitely cause damage to your Hydraulic components. And this damage is not included in the warranty range. So we strongly suggest you to use new clean oil or make sure the system oil are clean when using our parts.

CONTACT US
Product detail pictures:
